Mixing Tank Capacity: | 180L～250L |
Mixer Total Power: | 11KW |
Mixing Speed: | 2800r～4200r/min |
Save Formular Q.T.Y.: | 20 Groups. |
Control System: | PLC Touch Screen Control System |
PPG Tank: | 3Ton*1Set. |
POP Tank: | 3Ton*1Set. |
TDI Tank: | 2Ton*1Set. |
MC Tank: | 1Ton*1Set. |
Air Valves: | Euro Standard |
Auto Loading Pumps For PPG,POP,TDI,MC: | 4Sets(“Line”Brand Made In China) |
Transducers: | 4Sets |
Chiller(Both Cooling & Heating System): | 1Set*15KW(Made InTaiWan) |
Oil Hydraulic System: | 1Set |
Air Compressor: | 1Set*7.5KW |
Electric Float Top System: | 1Set(Electric) |
Auto Cleaning System: | 1Set |
Air Filtering System: | 1Set. |
Water Tower: | 1Set |
Water Pump: | 1Set. |
FoamingDensityRange: | 8～50kg/Cubicmeter. |
Outputs: | 96 Blocks/per day/8hrs(480m3/day) |
Match WithOne SquareMould: | L2100mm*W2100mm*H1300mm(To Be Requested) |
Match With One Cylinder Mould: | Dia1800mm*H2200mm(To Be Requested) |
Total Motor Power: | Approx 35KW. |
Machine N.W.: | Approx 6Ton |
Floor Space Required: | L10m*W10m*H6m. |
